SMSC LAN9420/LAN9420i

DATASHEET

Revision 1.6 (07-18-11)

Datasheet

PRODUCT FEATURES

LAN9420/LAN9420i

Single-Chip Ethernet Controller

with HP Auto-MDIX Support and

PCI Interface

Highlights

„

Optimized for embedded applications with 32-bit

RISC CPUs

„

Integrated descriptor based scatter-gather DMA and

IRQ deassertion timer effectively increase network
throughput and reduce CPU loading

„

Integrated Ethernet MAC with full-duplex support

„

Integrated 10/100 Ethernet PHY with HP Auto-MDIX

support

„

32-bit, 33MHz, PCI 3.0 compliant interface

„

Reduced power operating modes with PCI Power

Management Specification 1.1 compliance

„

Supports multiple audio & video streams over

Ethernet

Target Applications

„

Cable, satellite, and IP set-top boxes

„

Digital televisions

„

Digital video recorders

„

Home gateways

„

Digital media clients/servers

„

Industrial automation systems

„

Industrial/single board PC

„

Kiosk/POS enterprise equipment

Key Benefits

„

Integrated High-Performance 10/100 Ethernet

Controller

— Fully compliant with IEEE802.3/802.3u
— Integrated Ethernet MAC and PHY
— 10BASE-T and 100BASE-TX support
— Full- and half-duplex support
— Full-duplex flow control
— Preamble generation and removal
— Automatic 32-bit CRC generation and checking
— Automatic payload padding and pad removal
— Loop-back modes
— Flexible address filtering modes

– One 48-bit perfect address
– 64 hash-filtered multicast addresses
– Pass all multicast

– Promiscuous mode
– Inverse filtering
– Pass all incoming with status report

— Wakeup packet support
— Integrated 10/100 Ethernet PHY

– Auto-negotiation
– Automatic polarity detection and correction
– Supports HP Auto-MDIX
– Supports energy-detect power down

— Support for 3 status LEDs
— Receive and transmit TCP checksum offload

„

PCI Interface

— PCI Local Bus Specification Revision 3.0 compliant
— 32-bit/33-MHz PCI bus
— Descriptor based scatter-gather DMA enables zero-

copy drivers

„

Comprehensive Power Management Features

— Supports PCI Bus Power Management Interface

Specification, Revision 1.1

— Supports optional wake from D3cold

(via configuration strap option when Vaux is available)

— Wake on LAN
— Wake on link status change (energy detect)
— Magic packet wakeup

„

General Purpose I/O

— 3 programmable GPIO pins
— 2 GPO pins

„

Support for Optional EEPROM

— Serial interface provided for EEPROM
— Used to store PCI and MAC address configuration

values

„

Miscellaneous Features

— Big/Little/Mixed endian support for registers,

descriptors, and buffers

— IRQ deassertion timer
— General purpose timer

„

Single 3.3V Power Supply

— Integrated 1.8V regulator

„

Packaging

— Available in 128-pin VTQFP Lead-free RoHS Compliant

package

„

Environmental

— Available in commercial & industrial temperature ranges

/var/www/html/datasheet/sites/default/files/pdfhtml_dummy/9420-html.html
background image

Order Numbers:

LAN9420-NU For 128-PIN VTQFP, Lead-Free RoHS Compliant Package (0 to 70

o

C)

LAN9420i-NU For 128-PIN VTQFP, Lead-Free RoHS Compliant Package (-40

o

 to 85

o

C)

This product meets the halogen maximum concentration values per IEC61249-2-21

For RoHS compliance and environmental information, please visit

www.smsc.com/rohs

Single-Chip Ethernet Controller with HP Auto-MDIX Support and PCI Interface

Datasheet

Revision 1.6 (07-18-11)

2

SMSC LAN9420/LAN9420i

DATASHEET

80 ARKAY DRIVE, HAUPPAUGE, NY 11788 (631) 435-6000 or 1 (800) 443-SEMI

Copyright © 2011 SMSC or its subsidiaries. All rights reserved.
Circuit diagrams and other information relating to SMSC products are included as a means of illustrating typical applications. Consequently, complete information sufficient for
construction purposes is not necessarily given. Although the information has been checked and is believed to be accurate, no responsibility is assumed for inaccuracies. SMSC
reserves the right to make changes to specifications and product descriptions at any time without notice. Contact your local SMSC sales office to obtain the latest specifications
before placing your product order. The provision of this information does not convey to the purchaser of the described semiconductor devices any licenses under any patent
rights or other intellectual property rights of SMSC or others. All sales are expressly conditional on your agreement to the terms and conditions of the most recently dated
version of SMSC's standard Terms of Sale Agreement dated before the date of your order (the "Terms of Sale Agreement"). The product may contain design defects or errors
known as anomalies which may cause the product's functions to deviate from published specifications. Anomaly sheets are available upon request. SMSC products are not
designed, intended, authorized or warranted for use in any life support or other application where product failure could cause or contribute to personal injury or severe property
damage. Any and all such uses without prior written approval of an Officer of SMSC and further testing and/or modification will be fully at the risk of the customer. Copies of
this document or other SMSC literature, as well as the Terms of Sale Agreement, may be obtained by visiting SMSC’s website at http://www.smsc.com. SMSC is a registered
trademark of Standard Microsystems Corporation (“SMSC”). Product names and company names are the trademarks of their respective holders.
SMSC DISCLAIMS AND EXCLUDES ANY AND ALL WARRANTIES, INCLUDING WITHOUT LIMITATION ANY AND ALL IMPLIED WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND AGAINST INFRINGEMENT AND THE LIKE, AND ANY AND ALL WARRANTIES ARISING FROM ANY COURSE
OF DEALING OR USAGE OF TRADE. IN NO EVENT SHALL SMSC BE LIABLE FOR ANY DIRECT, INCIDENTAL, INDIRECT, SPECIAL, PUNITIVE, OR CONSEQUENTIAL
DAMAGES; OR FOR LOST DATA, PROFITS, SAVINGS OR REVENUES OF ANY KIND; REGARDLESS OF THE FORM OF ACTION, WHETHER BASED ON CONTRACT;
TORT; NEGLIGENCE OF SMSC OR OTHERS; STRICT LIABILITY; BREACH OF WARRANTY; OR OTHERWISE; WHETHER OR NOT ANY REMEDY OF BUYER IS HELD
TO HAVE FAILED OF ITS ESSENTIAL PURPOSE, AND WHETHER OR NOT SMSC HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
