AUIRF7805Q
V
DSS
30V
R
DS(on)
typ.
9.2m
I
D
13A
max.
11m
Description
Specifically designed for Automotive applications, these HEXFET®
Power MOSFET's in a Dual SO-8 package utilize the lastest
processing techniques to achieve extremely low on-resistance per
silicon area. Additional features of these Automotive qualified
HEXFET Power MOSFET's are a 150°C junction operating
temperature, fast switching speed and improved repetitive avalanche
rating. These benefits combine to make this design an extremely
efficient and reliable device for use in Automotive applications and a
wide variety of other applications.
The efficient SO-8 package provides enhanced thermal characteristics
and dual MOSFET die capability making it ideal in a variety of power
applications. This dual, surface mount SO-8 can dramatically reduce
board space and is also available in Tape & Reel.
Features
Advanced Planar Technology
Low
On-Resistance
Logic Level
N Channel MOSFET
Surface Mount
Available in Tape & Reel
150°C Operating Temperature
Lead-Free, RoHS Compliant
Automotive Qualified *
1
2015-10-5
HEXFET® is a registered trademark of Infineon.
*Qualification standards can be found at
www.infineon.com
AUTOMOTIVE GRADE
Symbol Parameter
Max.
Units
V
DS
Drain-Source
Voltage
30
V
GS
Gate-to-Source Voltage
± 12
I
D
@ T
A
= 25°C
Continuous Drain Current, V
GS
@ 10V
13
A
I
D
@ T
A
= 70°C
Continuous Drain Current, V
GS
@ 10V
10
I
DM
Pulsed Drain Current 100
P
D
@T
A
= 25°C
Maximum Power Dissipation 2.5
W
P
D
@T
A
= 70°C
Maximum Power Dissipation 1.6
Linear Derating Factor
0.02
W/°C
T
J
Operating Junction and
-55 to + 150
°C
T
STG
Storage Temperature Range
V
Absolute Maximum Ratings
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress
ratings only; and functional operation of the device at these or any other condition beyond those indicated in the specifications is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability. The thermal resistance
and power dissipation ratings are measured under board mounted and still air conditions. Ambient temperature (TA) is 25°C, unless
otherwise specified.
Thermal Resistance
Symbol Parameter
Typ.
Max.
Units
°C/W
R
JL
Junction-to-Drain Lead –––
20
R
JA
Junction-to-Ambient –––
50
SO-8
AUIRF7805Q
Base part number
Package Type
Standard Pack
Orderable Part Number
Form
Quantity
AUIRF7805Q
SO-8
Tape and Reel
4000
AUIRF7805QTR
G D S
Gate Drain Source
Top View
8
1
2
3
4
5
6
7
D
D
D
D
G
S
A
S
S
A
AUIRF7805Q
2
2015-10-5
Notes:
Repetitive rating; pulse width limited by max. junction temperature.
Pulse width
300µs; duty cycle 2%.
When mounted on 1" in square copper board, t < 10 sec.
Typ = measured - Q
OSS
R
is measured at T
J
of approximately 90°C.
Devices are 100% tested to these parameters.
Static @ T
J
= 25°C (unless otherwise specified)
Parameter Min.
Typ.
Max.
Units
Conditions
V
(BR)DSS
Drain-to-Source Breakdown Voltage
30
––– –––
V V
GS
= 0V, I
D
= 250µA
R
DS(on)
Static Drain-to-Source On-Resistance
–––
9.2
11
m
V
GS
= 4.5V, I
D
= 7.0A
V
GS(th)
Gate Threshold Voltage 1.0
–––
3.0
V
V
DS
= V
GS
, I
D
= 250µA
I
DSS
Drain-to-Source Leakage Current
––– ––– 70
µA
V
DS
= 30V, V
GS
= 0V
––– ––– 10
V
DS
= 24V, V
GS
= 0V
––– ––– 150
V
DS
= 24V,V
GS
= 0V,T
J
= 100°C
I
GSS
Gate-to-Source Forward Leakage
–––
––– 100
nA
V
GS
= 12V
Gate-to-Source Reverse Leakage
–––
––– -100
V
GS
= -12V
Dynamic Electrical Characteristics @ T
J
= 25°C (unless otherwise specified)
Q
g
Total Gate Charge
–––
22
31
nC
I
D
= 7.0A
Q
gs1
Pre -Vth Gate-to-Source Charge
–––
3.7
–––
V
DS
= 16V
Q
gs2
Post-Vth Gate-to-Source Charge
–––
1.4
–––
V
GS
= 5.0V
Q
gd
Gate-to-Drain Charge
–––
6.8
–––
Q
sw
Switch Charge (Qgs2 + Qgd)
–––
8.2 11.5
Q
oss
Output Charge
–––
3.0
3.6
nC V
DS
= 16V, V
GS
= 0V
R
G
Gate Resistance
0.5
–––
1.7
t
d(on)
Turn-On Delay Time
–––
16
–––
ns
V
DD
= 16V,V
GS
= 4.5V
t
r
Rise Time
–––
20
–––
I
D
= 7.0A
t
d(off)
Turn-Off Delay Time
–––
38
–––
R
G
= 2
t
f
Fall Time
–––
16
–––
Resistive Load
Diode Characteristics
Parameter
Min. Typ. Max. Units
Conditions
I
S
Continuous Source Current
––– ––– 2.5
A
MOSFET symbol
(Body Diode)
showing the
I
SM
Pulsed Source Current
––– ––– 106
integral reverse
(Body Diode)
p-n junction diode.
V
SD
Diode Forward Voltage –––
–––
1.2
V
T
J
= 25°C,I
S
= 7.0A,V
GS
= 0V
Q
rr
Reverse Recovery Charge –––
88
–––
di/dt = 700A/µs
V
DS
=16V, V
GS
= 0V, I
S
= 7.0A
Q
rr
Reverse Recovery Charge –––
55
–––
di/dt = 700A/µs (with 10BQ040)
V
DS
=16V, V
GS
= 0V, I
S
= 7.0A
nC
AUIRF7805Q
3
2015-10-5
Fig. 2 Typical Gate Charge vs.
Gate-to-Source Voltage
Fig. 4 Typical Source-Drain Diode Forward Voltage
Fig. 1 Normalized On-Resistance
vs. Temperature
Fig 5. Maximum Effective Transient Thermal Impedance, Junction-to-Ambient
0.1
1
10
0.4
0.5
0.6
0.7
0.8
0.9
V ,Source-to-Drain Voltage (V)
I
,
R
ev
er
se
D
ra
in
C
ur
re
nt
(A
)
SD
SD
V = 0 V
GS
T = 25 C
J
°
T = 150 C
J
°
Fig. 3 Typical Rds(on) vs. Gate-to-Source Voltage
AUIRF7805Q
4
2015-10-5
SO-8 Part Marking Information
SO-8 Package Outline
(Dimensions are shown in millimeters (inches)
e 1
D
E
y
b
A
A1
H
K
L
.189
.1497
0°
.013
.050 BASIC
.0532
.0040
.2284
.0099
.016
.1968
.1574
8°
.020
.0688
.0098
.2440
.0196
.050
4.80
3.80
0.33
1.35
0.10
5.80
0.25
0.40
0°
1.27 BASIC
5.00
4.00
0.51
1.75
0.25
6.20
0.50
1.27
M IN
M AX
M ILLIM ETERS
IN C H ES
M IN
M AX
D IM
8°
e
c
.0075
.0098
0.19
0.25
.025 BASIC
0.635 BASIC
8
7
5
6
5
D
B
E
A
e
6X
H
0.25 [ .010]
A
6
7
K x 45°
8X L
8X c
y
0.25 [ .010]
C A B
e1
A
A1
8X b
C
0.10 [ .004]
4
3
1
2
F O O T P R I N T
8 X 0 . 7 2 [ . 0 2 8 ]
6 . 4 6 [ . 2 5 5 ]
3 X 1 . 2 7 [ . 0 5 0 ]
4 . O U T L I N E C O N F O R M S T O J E D E C O U T L I N E M S - 0 1 2 A A .
N O T E S :
1 . D I M E N S I O N I N G & T O L E R A N C I N G P E R A S M E Y 1 4 . 5 M - 1 9 9 4 .
2 . C O N T R O L L I N G D I M E N S I O N : M I L L I M E T E R
3 . D I M E N S I O N S A R E S H O W N I N M I L L I M E T E R S [ I N C H E S ] .
5 D I M E N S I O N D O E S N O T I N C L U D E M O L D P R O T R U S I O N S .
6 D I M E N S I O N D O E S N O T I N C L U D E M O L D P R O T R U S I O N S .
M O L D P R O T R U S I O N S N O T T O E X C E E D 0 . 2 5 [ . 0 1 0 ] .
7 D I M E N S I O N I S T H E L E N G T H O F L E A D F O R S O L D E R I N G T O
A S U B S T R A T E .
M O L D P R O T R U S I O N S N O T T O E X C E E D 0 . 1 5 [ . 0 0 6 ] .
8 X 1 . 7 8 [ . 0 7 0 ]
Note: For the most current drawing please refer to IR website at
http://www.irf.com/package/
AUIRF7805Q
5
2015-10-5
SO-8 Tape and Reel (
Dimensions are shown in millimeters (inches)
330.00
(12.992)
MAX.
14.40 ( .566 )
12.40 ( .488 )
NOTES :
1. CONTROLLING DIMENSION : MILLIMETER.
2. OUTLINE CONFORMS TO EIA-481 & EIA-541.
FEED DIRECTION
TERMINAL NUMBER 1
12.3 ( .484 )
11.7 ( .461 )
8.1 ( .318 )
7.9 ( .312 )
NOTES:
1. CONTROLLING DIMENSION : MILLIMETER.
2. ALL DIMENSIONS ARE SHOWN IN MILLIMETERS(INCHES).
3. OUTLINE CONFORMS TO EIA-481 & EIA-541.
Note: For the most current drawing please refer to IR website at
http://www.irf.com/package/
AUIRF7805Q
6
2015-10-5
Qualification Information
Qualification Level
Automotive
(per AEC-Q101)
Comments: This part number(s) passed Automotive qualification. Infineon’s
Industrial and Consumer qualification level is granted by extension of the higher
Automotive level.
Moisture Sensitivity Level
SO-8
MSL1
ESD
Machine Model
Class M3 (+/- 300V)
†
AEC-Q101-002
Human Body Model
Class H1B (+/- 1000V)
†
AEC-Q101-001
Charged Device Model
Class C5 (+/- 2000V)
†
AEC-Q101-005
RoHS Compliant
Yes
Published by
Infineon Technologies AG
81726 München, Germany
©
Infineon Technologies AG 2015
All Rights Reserved.
IMPORTANT NOTICE
The information given in this document shall in no event be regarded as a guarantee of conditions or characteristics
(“Beschaffenheitsgarantie”). With respect to any examples, hints or any typical values stated herein and/or any
information regarding the application of the product, Infineon Technologies hereby disclaims any and all warranties and
liabilities of any kind, including without limitation warranties of non-infringement of intellectual property rights of any third
party.
In addition, any information given in this document is subject to customer’s compliance with its obligations stated in this
document and any applicable legal requirements, norms and standards concerning customer’s products and any use of
the product of Infineon Technologies in customer’s applications.
The data contained in this document is exclusively intended for technically trained staff. It is the responsibility of
customer’s technical departments to evaluate the suitability of the product for the intended application and the
completeness of the product information given in this document with respect to such application.
For further information on the product, technology, delivery terms and conditions and prices please contact your nearest
Infineon Technologies office (
www.infineon.com
).
WARNINGS
Due to technical requirements products may contain dangerous substances. For information on the types in question
please contact your nearest Infineon Technologies office.
Except as otherwise explicitly approved by Infineon Technologies in a written document signed by authorized
representatives of Infineon Technologies, Infineon Technologies’ products may not be used in any applications where a
failure of the product or any consequences of the use thereof can reasonably be expected to result in personal injury.
Revision History
Date Comments
10/5/2015
Updated datasheet with corporate template
Corrected ordering table on page 1.
† Highest passing voltage.
