SN54LS06, SN54LS16, SN74LS06, SN74LS16
HEX INVERTER BUFFERS/DRIVERS WITH
OPEN-COLLECTOR HIGH-VOLTAGE OUTPUTS
SDLS020A – MAY 1990
Copyright
1990, Texas Instruments Incorporated
1
POST OFFICE BOX 655303
•
DALLAS, TEXAS 75265
•
Converts TTL Voltage Levels to MOS
Levels
•
High Sink-Current Capability
•
Input Clamping Diodes Simplify System
Design
•
Open-Collector Driver for Indicator Lamps
and Relays
•
Package Options Include “Small Outline”
Packages, Ceramic Chip Carriers, and
Standard Plastic and Ceramic 300-mil DIPs
description
These monolithic hex inverter buffers/drivers
feature high-voltage open-collector outputs to
interface with high-level circuits (such as MOS), or
for driving high-current loads, and are also
characterized for use as inverter buffers for driving
TTL inputs. The
′
LS06 has a rated output voltage
of 30 V and the
′
LS16 has a rated output voltage
of 15 V. The maximum sink current for the
SN54LS06 and SN54LS16 is 30 mA and the
SN74LS06 and SN74LS16 is 40 mA.
These circuits are compatible with most TTL
families. Inputs are diode-clamped to minimize
transmission-effects, which simplifies design.
Typical power dissipation is 175 mW and average
propagation delay time is 8 ns.
The SN54LS06 and SN54LS16 are characterized over the full military temperature range of – 55
°
C to 125
°
C.
The SN74LS06 and SN74LS16 are characterized for operation from 0
°
C to 70
°
C.
logic symbol
†
logic diagram (positive logic)
1Y
2
1
1A
2Y
4
3Y
6
4Y
8
5Y
10
6Y
12
3
2A
5
3A
9
4A
11
5A
13
6A
1A
2A
3A
4A
5A
6A
1Y
2Y
3Y
4Y
5Y
6Y
† This symbol is in accordance with ANSI/IEEE Std 91-1984 and IEC
Publication 617-12.
Pin numbers shown are for D, J, and N packages.
1
3
5
9
11
13
2
4
6
8
10
12
1
2
3
4
5
6
7
14
13
12
11
10
9
8
1A
1Y
2A
2Y
3A
3Y
GND
V
CC
6A
6Y
5A
5Y
4A
4Y
SN54LS06, SN54LS16 . . . J PACKAGE
SN74LS06, SN74LS16 . . . D OR N PACKAGE
(T0P VIEW)
3
2
1 20 19
9 10 11 12 13
4
5
6
7
8
18
17
16
15
14
6Y
NC
5A
NC
5Y
2A
NC
2Y
NC
3A
SN54LS06, SN54LS16 . . . FK PACKAGE
(T0P VIEW)
1Y
1A
NC
4Y
4A
6A
3Y
GND
NC
NC – No internal connection
V
CC
UNLESS OTHERWISE NOTED this document contains PRODUCTION
DATA information current as of publication date. Products conform to
specifications per the terms of Texas Instruments standard warranty.
Production processing does not necessarily include testing of all
parameters.
PRODUCT PREVIEW information concerns products in the formative or
design phase of development. Characteristic data and other
specifications are design goals. Texas Instruments reserves the right to
change or discontinue these products without notice.
VOH
High-level output voltage
V
SN54LS06, SN54LS16, SN74LS06, SN74LS16
HEX INVERTER BUFFERS/DRIVERS WITH
OPEN-COLLECTOR HIGH-VOLTAGE OUTPUTS
SDLS020A – MAY 1990
2
POST OFFICE BOX 655303
•
DALLAS, TEXAS 75265
schematic (each gate)
Input
VCC
Output
GND
9 k
Ω
1 k
Ω
2 k
Ω
2 k
Ω
2.5 k
Ω
2.5 k
Ω
15 k
Ω
absolute maximum ratings over operating free-air temperature range (unless otherwise noted)
†
Supply voltage, V
CC
7 V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input voltage, V
I
(see Note 1)
5.5 V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output voltage, V
O
(see Notes 1 and 2): SN54LS06, SN74LS06
30 V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SN54LS16, SN74LS16
15 V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating free-air temperature range: SN54LS06, SN54LS16
– 55
°
C to 125
°
C
. . . . . . . . . . . . . . . . . . . . . . .
SN74LS06, SN74LS16
0
°
C to 70
°
C
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage temperature range
– 65
°
C to 150
°
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
† Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. This are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
NOTES: 1. Voltage values are with respect to network ground terminal.
2. This is the maximum voltage that should be applied to any output when it is in the off state.
recommended operating conditions
SN54LS06
SN74LS06
SN54LS16
SN74LS16
UNIT
MIN
NOM
MAX
MIN
NOM
MAX
VCC
Supply voltage
4.5
5
5.5
4.75
5
5.25
V
VIH
High-level input voltage
2
2
V
VIL
Low-level input voltage
0.8
0.8
V
’LS06
30
30
’LS16
15
15
IOL
Low-level output current
30
40
mA
TA
Operating free-air temperature
– 55
125
0
70
°
C
IOH
VCC = MIN,
VIL = 0.8 V
mA
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
A
Y
RL = 110
Ω
,
CL = 15 pF
ns
PRODUCT PREVIEW information concerns products in
the formative or design phase of development.
Characteristic data and other specifications are design
goals. Texas Instruments reserves the right to change or
discontinue these products without notice.
SN54LS06, SN54LS16, SN74LS06, SN74LS16
HEX INVERTER BUFFERS/DRIVERS WITH
OPEN-COLLECTOR HIGH-VOLTAGE OUTPUTS
SDLS020A – MAY 1990
3
POST OFFICE BOX 655303
•
DALLAS, TEXAS 75265
electrical characteristics over recommended operating free-air temperature range (unless
otherwise noted)
SN54LS06
SN74LS06
PARAMETER
TEST CONDITIONS†
SN54LS16
SN74LS16
UNIT
MIN
TYP‡
MAX
MIN
TYP‡
MAX
VIK
VCC = MIN,
II = – 12 mA
– 1.5
– 1.5
V
’LS06,
VOH = 30 V
0.25
0.25
’LS16,
VOH = 15 V
0.25
0.25
IOL = 16 mA
0.25
0.4
0.25
0.4
VOL
VCC = MIN,
VIH = 2 V
IOL = 30 mA
0.7
V
IOL = 40 mA
0.7
II
VCC = MAX,
VI = 7 V
1
1
mA
IIH
VCC = MAX,
VI = 2.4 V
20
20
µ
A
IIL
VCC =MAX,
VI = 0.4 V
– 0.2
– 0.2
mA
ICCH
VCC = MAX
18
18
mA
ICCL
VCC = MAX
60
60
mA
† For conditions shown as MIN or MAX, use the appropriate value specified under recommended operating conditions.
‡ All typical values are at VCC = 5 V, and TA = 25
°
C.
switching characteristics, V
CC
= 5 V, T
A
= 25
°
C (see Note 3)
FROM
TO
(INPUT)
(OUTPUT)
tPLH
7
15
tPHL
10
20
NOTE 3: Load circuit and voltage waveforms are shown in Section 1 of
TTL Logic Data Book, 1988.
